K Series Camera Scanner

Joyusing K Series

Camera Scanner

OVERVIEW

High specification and performance desktop camera scanner with multiple optional integration modules, widely applied to the field of government offices, registration windows and medical institutions.
HIGHLIGHTS

5.0MP 1/4" CMOS | Foldable Design | Touch Control LED | TWAIN Interface | Fixed Focus Lens | ABBYY OCR
DATASHEET

Download - K Series Document Scanner Datasheet ⇩

REQUEST A QUOTE

｜OVERVIEW

Built-in Larger Size Condensor Lens with Higher Optical Standard

Different megapixel comes out with different images clarity. Many ones are available for your needs, including 5.0 / 12.0 / 16.0MP.

Large Shooting Area of A3

The camera scanner enables capturing an extensive shooting area of 297mm x 420mm with superb color reproduction and no distortion.

Powerful OCR for Diverse Formats

It supports 180 languages. An easy click of OCR to create editable Word, Excel, TXT, PDF, and TIFF format in color and gray.

Customization Base on Diverse Demands

Optional HDR camera / dual lens camera/ ID card reader/fingerprint reader/IC card reader

Touch Control LED Lights

Three levels of brightness by touch control. Meeting lighting requirements in various environment conditions.

Mature Doccamera SDK and TWAIN Driver

Doccamera SDK is Joyusing self-developed control kit, supporting Java, C#, VC++, VB, and other mainstream languages. Simple, efficient and stable.

｜SPECIFICATIONS

HEIGHT x WIDTH x DEPTH

8.58" x 11.26" x 14.37" / 218mm x 286mm x 365mm

SENSOR

1/2.5" CMOS

RESOLUTION OPTIONS

5.0MP / 10.0MP / 16.0MP

FOCUS MODE

Fixed Focus

SYSTEM

Windows XP and above

SHOOTING AREA

Max. A3=16.5" x 11.7" / 420mm x 297mm

LENS

F=2.8

ILLUMINATION SYSTEM

6 LED Fill-in Lights

INTERFACE

USB2.0

｜DOWNLOAD

DOCUMENTS

Datasheet

SOFTWARE & DRIVER

Windows
